MCS 3020 10 Studs Brake System
Technical Details
Position number |
Part code |
Part name |
Description |
Quantity |
|---|---|---|---|---|
| 220 | 10.20.220.71510 | HUB | 9-12 TON 10 ST. - MCS 3020 - WITH ABS GEAR |
2 PCS |
| 10.20.220.71520 | 9-12 TON 10 ST. - MCS 3020 - WITHOUT ABS GEAR |
|||
| 230 | 10.20.230.12100.A | DRUM | MCS 3020 - 10 STUD |
2 PCS |
| 7904 - 7905 | 90.26.7905.00 | S.T STUD |
M22 x 1,5 x 90 - 10.9 PHOSPHATE COATED |
20 PCS |
| 90.26.7905.01 | M22 x 1,5 x 90 - 10.9 DACROMED COATED |
|||
| 90.26.7904.00 | D.T STUD |
M22 x 1,5 x 110 - 10.9 PHOSPHATE COATED |
||
| 90.26.7904.01 | M22 x 1,5 x 110 - 10.9 DACROMED COATED |
|||
| 4501 | 90.16.4501.00.A | INNER BEARING | 33118 - Q | 2 PCS |
| 7750 | 90.24.7750.00.A | OIL SEAL |
Ø110 x Ø160 x 13 | 2 PCS |
| 4502 | 90.16.4502.00.A | OUTER BEARING | 33213 - Q | 2 PCS |
| 270 | 10.20.270.11000 | AXLE NUT | STANDARD TYPE | 2 PCS |
| 280 | 10.20.280.10000 | SECURITY PIN | STANDARD TYPE | 2 PCS |
| 290 | 10.20.290.10000 | SECURITY RING |
STANDARD TYPE |
2 PCS |
| 300 | 10.20.300.10000 | SECURITY PIN & RING |
STANDARD TYPE |
2 PCS |
| 7700 | 90.24.7700.00.A | O-RİNG | Ø4 x 130 | 2 PCS |
| 310 | 10.20.310.12200 | HUB CAP |
9-12 TON ELECTROSTATIC PAINTED |
2 PCS |
| 3222 | 90.11.3222.01 | STUD NUT |
M22 x 1,5 PHOSPHATE COATED |
2 PCS |
| 90.11.3222.11 | M22 x 1,5 DACROMED COATED |
|||
| 7911 | 90.26.7911.00 | STUD NUT CAP |
- | 20 PCS |
| 4750 | 90.17.4750.00 | SENSOR CABLE |
WABCO | 2PCS |
Abbreviations S.T. = Single Tyre, D.T. = Double Tyre, ST. = Stud
