Products ›
Trailer Leaf Springs › Products
Leaf Springs - Bogie Type
Mounting Type:
Bogie Type
Section of Layers:
120 mm x 16 mm , 120 mm x 18 mm
Technical Details
Product code |
Number of layers |
Number of main layers (A) |
Section of layers |
Total lenght (L) mm) |
Weight (kg) |
---|---|---|---|---|---|
20.22.150.10000 | 11 | 5 | 120 mm x 16 mm | 1780 | 218 |
20.22.150.11000 | 13 | 6 | 120 mm x 16 mm | 1780 | 256 |
20.22.150.12000 | 16 | 8 | 120 mm x 16 mm | 1780 | 314 |
20.22.150.16000 | 16 | 8 | 120 mm x 18 mm | 1780 | 357 |
20.22.150.15000 | 18 | 8 | 120 mm x 16 mm | 1780 | 352 |
